Performance Carbide Coolant Drills for a Variety of Materials & Applications
Steel
Stainless Steel
Cast Iron
Non-Ferrous
Hardened Steel
Heat Resistant Super Alloy
Steel
Stainless Steel
Cast Iron
Non-Ferrous
Hardened Steel
Heat Resistant Super Alloy
PDF generation may take time depending on details of the product.
| Diameter - Metric (D) | 10 |
| Diameter - Inch (D) | 0.3937 |
| Flute Length - Metric (FL) | 47 |
| Overall Length - Metric (L) | 89 |
| Shank Diameter - Metric (d) | 10 |
| Cutting Diameter Tolerance - Inch | +0.0002 / +0.0008 |
| Cutting Diameter Tolerance - Metric | +0.006 / +0.021 |
| Cutting Diameter Tolerance Specification | m7 |
| Substrate | Carbide |
| Surface Treatment | EgiAs |
| Length of Cut - Specification | STUB |
| Drilling L/D Ratio (xD) | 3 |
| Helix Angle - Degree | 30 |
| Point Angle - Degree (α) | 140 |
| Point Thinning | R Thinning |
| Helix Direction | RH |
| Cutting Direction | RH |
| Coolant Thru | Yes |
| Number of Flutes | 2 |
| Shank Tolerance | h6 |
| View Catalog Page | Here |
| View Speed and Feed Page | Here |
| DXF Drawing | Download |
| STP Drawing | Download |
