OSG PHOENIX P3D

Indexable drill series for efficient, stable hole processing

EDP: 7803278
P3D6200FS40M16
Description
Indexable_-_Drill_-_PHOENIX_PD_-_List_78032_-_Catalog
Description
PHOENIX PD is an indexable drill series designed for efficient, stable holemaking up to 5XD. It is an ideal solution for a wide variety of materials such as carbon and alloy steel, stainless steel, cast iron, and non-ferrous materials.
Features & Benefits
OSG's proprietary design for deeper drilling Stable drilling depths up to 5XD; normally difficult to achieve with a double-flute, single-edge indexable drill
The center and peripheral cutting edges use the same 4-corner insert More economical and simplified insert management
Unique flute design with high precision finish and integrated chip breaker Excellent chip evacuation by breaking the cutting chips into small pieces
Stocked
ALTERNATIVE PRODUCT
VIEW PRODUCT
CONTACT US
Loading...

MOQ: 1

Preview PDF

PDF generation may take time depending on details of the product.

Diameter - Metric (D)62
Diameter Max - Metric (D Max)62.8
Drilling Depth - Metric (l1)186
Overall Length - Metric (L)286
Shank Diameter - Metric (d)40
Shank Length - Metric (l2)70
Number of Flutes2
Drilling L/D Ratio (xD)3
SubstrateTOOL STEEL
Body TypeFlat Shank
Helix DirectionRH
Cutting DirectionRH
Coolant ThruYes
Applicable InsertXCMT16
Max Offset Amount - Metric (A)0.4
Product CategoryIndexable Insert Drill
View Catalog PageHere
View Speed and Feed PageHere
DXF DrawingDownload
STP DrawingDownload
