High Performance Diamond Coated Ball Mills for Graphite & Non-Ferrous Materials
Non-Ferrous
Other Material
Non-Ferrous
Other Material
IL: 0 In stock
CA: 3 In stock
MOQ: 1
PDF generation may take time depending on details of the product.
| Diameter - Metric (D) | 12 |
| Corner Radius - Metric (R) | 6 |
| Length of Cut - Metric (Lc) | 12 |
| Length of Cut - Specification | STUB |
| Neck Diameter - Metric (d1) | 11.4 |
| Neck Length - Metric (L1) | 48 |
| Overall Length - Metric (L) | 150 |
| Shank Diameter - Metric (d) | 12 |
| Shank Tolerance | h6 |
| Substrate | Carbide |
| Helix Angle - Degree | 30 |
| Helix Direction | RH |
| Mill Type | Single End |
| Number of Flutes | 4 |
| Surface Treatment | DIAMOND |
| Weldon Flat | No |
| Cutting Direction | RH |
| Cutting Type | Center Cutting |
| Coolant Thru | No |
| End Cut Type | Ball Nose |
| Radius Tolerance - Metric | +0 / -0.015 |
| Type (feature) | Long Shank |
| View Catalog Page | Here |
| View Speed and Feed Page | Here |
