MILLING/INDEXABLE - MILLING/SHOULDER CUTTERS/52901

OSG PHOENIX PSF BORE

90 Degree indexable shoulder cutter for face milling

EDP: 52901001
PSF09R250A075-7
Description
Indexable_-_Mill_-_PHOENIX_PSF_-_List_52901_-_Bore_-_Catalog
Description
PHOENIX PSF is a series of 90° indexable shoulder end mills and facemills. Utilizing a 4-cornered insert, highly economical milling is possible in a wide variety of materials.
Features & Benefits
Sharp 3-dimensional chip breaker Reduced cutting forces
Square insert with 4 cutting edges High performance with long insert life and low cost per edge
Compact insert size for lighter depths of cut Superior performance in face milling applications
End mill and face mill styles, Inch and Metric Complete Offering
Stocked
ALTERNATIVE PRODUCT
VIEW PRODUCT
CONTACT US
Loading...

MOQ: 1

Preview PDF

PDF generation may take time depending on details of the product.

Diameter - Inch (D)2.5
Bore Diameter - Inch (d3)0.75
Flange Diameter - Inch (D2)1.968
Length of Cut - Inch (Lc)0.197
Body Height - Inch (H)1.575
SubstrateTOOL STEEL
Number of Flutes7
Applicable InsertSD_T09
Body TypeBore
Coolant ThruYes
Cutting DirectionRH
Keyway Depth - Inch (b)0.197
Keyway Width - Inch (a)0.315
Type1
UnitsInch
View Catalog PageHere
View Speed and Feed PageHere
DXF DrawingDownload
STP DrawingDownload
