MILLING/INDEXABLE - MILLING/MILL ACCESSORIES/52600

OSG PHOENIX SF SA

Screw-Fit End Mill Shank

EDP: 52600011
SF-M06SA0500-2500CS
Description
Indexable_-_Mill_-_PHOENIX_SF_-_List_52600_-_Arbor_-_Steel_Shank_-_Catalog
Description
PHOENIX SF is a series of modular indexable end mills, with PSE, PRC, PHC, PFB and PFR styles for a variety of applications.
Features & Benefits
Straight shank, BT taper and HSK taper arbors Capable of extended overhangs
Uses same inserts as PHOENIX end mill and facemill styles More economical and simplified insert management
End mill style, Inch and Metric Complete Offering
Modular body style Quick and easy to change system and provides milling flexibility
Stocked
ALTERNATIVE PRODUCT
VIEW PRODUCT
CONTACT US
Loading...

MOQ: 1

Preview PDF

PDF generation may take time depending on details of the product.

DesignationSF-M06SA0500-2500CS
Pilot Diameter - Inch (Da)0.256
Thread Size - Metric (Dg)M6
Neck Diameter - Inch (d1)0.433
Neck Length - Inch (L1)2.5
Shank Diameter - Inch (d)0.5
Overall Length - Inch (L)5.5
Body TypeCylindrical Shank Carbide
Coolant ThruYes
SubstrateCarbide
View Catalog PageHere
DXF DrawingDownload
STP DrawingDownload
