MILLING/INDEXABLE - MILLING/EXCHANGEABLE HEAD END MILLS/52300

OSG PHOENIX PXM SA/TPA

Exchangable head end mill series for superior surface finish

EDP: 52300013
PXMZ-C16SA0625-L600CS
Description
Indexable_-_Mill_-_PHOENIX_PXM_-_List_52300_-_Exchangeable_Head_-_Arbor_-_Straight_Shank_-_Catalog
Description
PHOENIX PXM is an exchangeable head end mill series for superior surface finish and precision in a variety of applications.
Features & Benefits
Radial runout less than 15µm and axial repeatability ±30µm High accuracy and repeatability
2-face contact (end face and taper) and buttress thread Fast and highly rigid clamping
End mill style, Inch and Metric Complete Offering
OSG's proven cutting geometries and coatings High performance in a variety of applications and materials
Stocked
ALTERNATIVE PRODUCT
VIEW PRODUCT
CONTACT US
Loading...

MOQ: 1

Preview PDF

PDF generation may take time depending on details of the product.

Neck Diameter - Inch (d1)0.613
Neck Length - Inch (L1)3.25
Overall Length - Inch (L)6
Shank Diameter - Inch (d)0.625
SubstrateCarbide
Applicable Head - Inch0.625
Body TypeCylindrical Shank Carbide
Connection Size (Cs)C16
Coolant ThruNo
Cutting DirectionRH
Type1
UnitsInch
View Catalog PageHere
DXF DrawingDownload
STP DrawingDownload
NotesWrench included with body.
