THREADING/STYLE/THREAD MILLS/41100

EXOCARB OT-SFT-PNGT/WX-PNC

Ideal for Steels, Exotics and Difficult to Machine Materials

EDP: 4110001111
M16 x 1.5 4FL EXOCARB THD MILL EXO
Description
Taps_-_Tap_-_EXOCARB_-_List_41100_-_Thread_Mills_-_Catalog
P

Steel

Low Carbon Steel : 1010; 1018
Medium Carbon Steel : 1035; 1045
Alloy Steels : 4140; 4340
High Carbon Steel : 1065
Good
Best
M

Stainless Steel

Stainless Steels : 17-4PH
Stainless Steels : 300
Stainless Steels : 400
Good
Best
K

Cast Iron

Cast Iron
Good
Best
N

Non-Ferrous

Aluminum : 6061; 7075
Aluminum : Casting
Good
Best
H

Hardened Steel

Hardened Steels : 35 HRC
Hardened Steels : 35-45 HRC
Good
Best
S

Heat Resistant Super Alloy

Nickel Alloy : Inconel
Titanium : 6AL4V (30HRC)
Good
Best
P

Steel

Low Carbon Steel : 1010; 1018
Medium Carbon Steel : 1035; 1045
Alloy Steels : 4140; 4340
High Carbon Steel : 1065
Good
Best
M

Stainless Steel

Stainless Steels : 17-4PH
Stainless Steels : 300
Stainless Steels : 400
Good
Best
K

Cast Iron

Cast Iron
Good
Best
N

Non-Ferrous

Aluminum : 6061; 7075
Aluminum : Casting
Good
Best
H

Hardened Steel

Hardened Steels : 35 HRC
Hardened Steels : 35-45 HRC
Good
Best
S

Heat Resistant Super Alloy

Nickel Alloy : Inconel
Titanium : 6AL4V (30HRC)
Good
Best
Description
The newly expanded EXOCARB thread mills now includes longer lengths, miniature mills and coolant-fed thread mills. All utilizing OSG's premium sub-micrograin carbide for hardness, helical flutes for free cutting action and our EXO multi-layered coating for ultimate wear resistance and tool life.
Features & Benefits
Inch, Metric and Pipe For internal inch, metric and pipe threads
Optimized flute geometry Reduced cutting forces
OSG's EXO multi-layered TiAlN coating Improves wear resistance for extended tool life
Stocked
ALTERNATIVE PRODUCT
VIEW PRODUCT
CONTACT US
Loading...

MOQ: 1

Preview PDF

PDF generation may take time depending on details of the product.

Thread Size - MetricM16
Thread TypeMF
Pitch1.5
Major Diameter - Metric12
Overall Length - Metric (L)95
Shank Diameter - Metric (d)12
SubstrateCarbide
Surface TreatmentEXO
Coolant ThruNo
Number of Flutes4
Cutting DirectionRH
Helix Angle - Degree11-30
Helix DirectionRH
View Catalog PageHere
View Speed and Feed PageHere
STP DrawingDownload
NotesFor internal threads only
