THREADING/STYLE/SPIRAL POINT/337Ni

EXOPRO WHR-Ni-POT

Taps Designed for Nickel-Based Alloys

EDP: 3370008322
8-32 H2 3S/P PLUG EXOPRO WHR-Ni HR
Description
Taps_-_Tap_-_EXOPRO_WHR-Ni_-_List_337Ni_-_Spiral_Pointed_Taps
M

Stainless Steel

Stainless Steels : 17-4PH
Good
Best
H

Hardened Steel

Hardened Steels : 45-50 HRC
Good
Best
S

Heat Resistant Super Alloy

Nickel Alloy : Inconel
Good
Best
M

Stainless Steel

Stainless Steels : 17-4PH
Good
Best
H

Hardened Steel

Hardened Steels : 45-50 HRC
Good
Best
S

Heat Resistant Super Alloy

Nickel Alloy : Inconel
Good
Best
Description
The EXOPRO-WHR-Ni spiral point tap series is one of OSG’s latest innovations for nickel-based alloy applications. The WHR-Ni series features a unique rake angle to improve cutting edge rigidity, which helps prevent chipping and prolongs tool life. With the addition of OSG’s patented HR coating, wear resistance and tool life can be substantially prolonged versus the competition.
Features & Benefits
OSG’s patented HR coating Improves wear resistance to prolong tool life.
Unique rake angle Improves cutting edge rigidity to prevent edge chipping.
Stocked
ALTERNATIVE PRODUCT
VIEW PRODUCT
CONTACT US
Loading...

MOQ: 1

Preview PDF

PDF generation may take time depending on details of the product.

Thread Size - NumberNo. 8
Thread TypeUNC
Threads Per Inch32
Thread LimitH2
Chamfer TypePlug (5P)
Major Diameter - Inch0.164
Thread Length - Inch (Lc)0.751
Tap Drill Size Min - Inch0.13
Tap Drill Size Max - Inch0.139
Overall Length - Inch (L)2.48
Square Length - Inch (Ik)0.25
Shank Diameter - Inch (d)0.168
Square Width - Inch (k)0.131
STI ThreadNo
SubstrateVC-10
Surface TreatmentHR
Coolant ThruNo
Number of Flutes3
Cutting DirectionRH
Helix Angle - Degree0
Interrupted ThreadNo
View Catalog PageHere
