Taps Designed for Nickel-Based Alloys
Stainless Steel
Hardened Steel
Heat Resistant Super Alloy
Stainless Steel
Hardened Steel
Heat Resistant Super Alloy
PDF generation may take time depending on details of the product.
| Thread Size - Inch | 5/16 |
| Thread Type | UNC |
| Threads Per Inch | 18 |
| Thread Limit | H5 |
| Chamfer Type | Modified Bottom (2.5P) |
| Major Diameter - Inch | 0.3125 |
| Thread Length - Inch (Lc) | 0.665 |
| Tap Drill Size Min - Inch | 0.252 |
| Tap Drill Size Max - Inch | 0.265 |
| Neck Length - Inch (L1) | 1.378 |
| Overall Length - Inch (L) | 3.543 |
| Square Length - Inch (Ik) | 0.375 |
| Shank Diameter - Inch (d) | 0.318 |
| Square Width - Inch (k) | 0.238 |
| STI Thread | No |
| Substrate | VC-10 |
| Surface Treatment | HR |
| Coolant Thru | No |
| Number of Flutes | 3 |
| Cutting Direction | RH |
| Helix Angle - Degree | 11 |
| Helix Direction | RH |
| Interrupted Thread | No |
| View Catalog Page | Here |
| STP Drawing | Download |
