| Thread Size - Inch | 7/16 |
| Thread Type | UNF |
| Threads Per Inch | 20 |
| Class of Fit | 2B |
| Chamfer Type | Bottom (1.5P) |
| Major Diameter - Inch | 0.4375 |
| Thread Length - Inch (Lc) | 0.858 |
| Tap Drill Size Min - Inch | 0.383 |
| Tap Drill Size Max - Inch | 0.395 |
| Overall Length - Inch (L) | 3.937007 |
| Square Length - Inch (Ik) | 0.40625 |
| Shank Diameter - Inch (d) | 0.323 |
| Square Width - Inch (k) | 0.242 |
| STI Thread | No |
| Substrate | Carbide |
| Surface Treatment | BRIGHT |
| Coolant Thru | No |
| Number of Flutes | 4 |
| Cutting Direction | RH |
| Helix Angle - Degree | 0 |
| Interrupted Thread | No |
| View Catalog Page | Here |
| STP Drawing | Download |
| Notes | Other coatings are available upon request. |
