Advanced Performance Highly Efficient Multi-Purpose Forming Tap
Steel
Stainless Steel
Non-Ferrous
Hardened Steel
Heat Resistant Super Alloy
Steel
Stainless Steel
Non-Ferrous
Hardened Steel
Heat Resistant Super Alloy
PDF generation may take time depending on details of the product.
| Thread Size - Number | No. 8 |
| Thread Type | UNF |
| Threads Per Inch | 36 |
| Thread Limit | H5 |
| Chamfer Type | Bottom (1.5P) |
| Major Diameter - Inch | 0.164 |
| Thread Length - Inch (Lc) | 0.375 |
| Tap Drill Size Min - Inch | 0.148296 |
| Tap Drill Size Max - Inch | 0.152484 |
| Neck Length - Inch (L1) | 0.827 |
| Overall Length - Inch (L) | 2.481 |
| Square Length - Inch (Ik) | 0.25 |
| Shank Diameter - Inch (d) | 0.168 |
| Square Width - Inch (k) | 0.131 |
| STI Thread | No |
| Substrate | VC-10 |
| Surface Treatment | VI |
| Coolant Thru | No |
| Cutting Direction | RH |
| Interrupted Thread | No |
| View Catalog Page | Here |
