Advanced Performance Carbide Coolant-Through Taps for Cast Iron and Aluminum Alloy
Cast Iron
Non-Ferrous
Cast Iron
Non-Ferrous
PDF generation may take time depending on details of the product.
| Thread Size - Inch | 1/4 |
| Thread Type | UNC |
| Threads Per Inch | 20 |
| Thread Limit | H5 |
| Chamfer Type | Bottom (1.5P) |
| Major Diameter - Inch | 0.25 |
| Thread Length - Inch (Lc) | 0.598 |
| Tap Drill Size Min - Inch | 0.196 |
| Tap Drill Size Max - Inch | 0.207 |
| Neck Length - Inch (L1) | 1.181 |
| Overall Length - Inch (L) | 3.14 |
| Square Length - Inch (Ik) | 0.3125 |
| Shank Diameter - Inch (d) | 0.255 |
| Square Width - Inch (k) | 0.191 |
| STI Thread | No |
| Substrate | Carbide |
| Surface Treatment | BRIGHT |
| Coolant Thru | Yes |
| Number of Flutes | 3 |
| Cutting Direction | RH |
| Helix Angle - Degree | 15 |
| Helix Direction | RH |
| Interrupted Thread | No |
| View Catalog Page | Here |
| Notes | Other coatings are available upon request. Note: Reduce SFM 50% - 70% while using external coolant. |
