THREADING/STYLE/FORMING/16150

EXOPRO OIL-S-XPF

Extreme Performance Forming Tap

EDP: 1615024309
M24 x 3.0 D9 2.5P EXOPRO OIL-S-XPF V
Description
Taps_-_Tap_-_EXOPRO_XPF-OIL_-_List_16150_-_Forming_Taps_-_Catalog
P

Steel

Alloy Steels : 4140; 4340
Die Steels
High Carbon Steel : 1065
Low Carbon Steel : 1010; 1018
Medium Carbon Steel : 1035; 1045
Good
Best
M

Stainless Steel

Stainless Steels : 17-4PH
Stainless Steels : 300
Stainless Steels : 400
Good
Best
N

Non-Ferrous

Aluminum : 6061; 7075
Aluminum : Casting
Good
Best
H

Hardened Steel

Hardened Steels : 35-45 HRC
Hardened Steels : 35 HRC
Good
Best
S

Heat Resistant Super Alloy

Nickel Alloy : Inconel
Titanium : 6AL4V (30HRC)
Good
Best
P

Steel

Alloy Steels : 4140; 4340
Die Steels
High Carbon Steel : 1065
Low Carbon Steel : 1010; 1018
Medium Carbon Steel : 1035; 1045
Good
Best
M

Stainless Steel

Stainless Steels : 17-4PH
Stainless Steels : 300
Stainless Steels : 400
Good
Best
N

Non-Ferrous

Aluminum : 6061; 7075
Aluminum : Casting
Good
Best
H

Hardened Steel

Hardened Steels : 35-45 HRC
Hardened Steels : 35 HRC
Good
Best
S

Heat Resistant Super Alloy

Nickel Alloy : Inconel
Titanium : 6AL4V (30HRC)
Good
Best
Description
The EXOPRO S-XPF X Performer Taps represent a new evolution in forming tap technology. These form taps generate up to 50% less torque versus other forming taps, making it feasible to tap materials up to 40 HRC and sizes up to or exceeding 1" in diameter.
Features & Benefits
40-50% less machining torque Longer life at faster speeds and the ability to use larger forming taps.
Coolant-fed version also available (S-XPF) For those with coolant-fed spindles, even more performance can be achieved.
DIN Overall Length Additional length provides greater reach capabilities.
Fluteless Forming Tap Produces no chips, making it up to 17X more durable than cut taps.
Stocked
ALTERNATIVE PRODUCT
VIEW PRODUCT
CONTACT US
Loading...

MOQ: 1

Preview PDF

PDF generation may take time depending on details of the product.

Thread Size - MetricM24
Thread TypeM
Pitch3
Thread LimitD9
Chamfer TypeModified Bottom (2.5P)
Major Diameter - Metric24
Thread Length - Metric (Lc)30
Tap Drill Size Min - Metric22.47
Tap Drill Size Max - Metric22.776
Neck Length - Metric (L1)68.4
Overall Length - Metric (L)160
Shank Diameter - Metric (d)19.304
Square Length - Metric (Ik)19.05
Square Width - Metric (k)14.478
STI ThreadNo
SubstrateHSS-CO
Surface TreatmentV
Coolant ThruYes
Cutting DirectionRH
Interrupted ThreadNo
View Catalog PageHere
STP DrawingDownload
NotesFor Stainless Steel, please use non-water-soluble coolant or highly concentrated water-soluble coolant.
