| Thread Size - Inch | 5/16 |
| Thread Type | UNC |
| Threads Per Inch | 18 |
| Thread Limit | H9 |
| Chamfer Type | Bottom (1.5P) |
| Major Diameter - Inch | 0.3125 |
| Thread Length - Inch (Lc) | 0.665354 |
| Tap Drill Size Min - Inch | 0.284167 |
| Tap Drill Size Max - Inch | 0.289833 |
| Neck Length - Inch (L1) | 1.125984 |
| Overall Length - Inch (L) | 2.719 |
| Square Length - Inch (Ik) | 0.375 |
| Shank Diameter - Inch (d) | 0.318 |
| Square Width - Inch (k) | 0.238 |
| STI Thread | No |
| Substrate | HSS-CO |
| Surface Treatment | TiN |
| Coolant Thru | No |
| Cutting Direction | RH |
| Interrupted Thread | No |
| View Catalog Page | Here |
| Notes | Other coatings are available upon request. |
