| Thread Size - Number | No. 10 |
| Thread Type | UNF |
| Threads Per Inch | 32 |
| Thread Limit | H3 |
| Chamfer Type | Bottom (1.5P) |
| Major Diameter - Inch | 0.19 |
| Thread Length - Inch (Lc) | 0.492 |
| Tap Drill Size Min - Inch | 0.174063 |
| Tap Drill Size Max - Inch | 0.17725 |
| Neck Length - Inch (L1) | 0.866 |
| Overall Length - Inch (L) | 2.375 |
| Square Length - Inch (Ik) | 0.25 |
| Shank Diameter - Inch (d) | 0.194 |
| Square Width - Inch (k) | 0.152 |
| STI Thread | No |
| Substrate | HSS-CO |
| Surface Treatment | TiCN |
| Coolant Thru | No |
| Cutting Direction | RH |
| Interrupted Thread | No |
| View Catalog Page | Here |
| STP Drawing | Download |
| Notes | Other coatings are available upon request. |
