Ideal for Aerospace Fasterner Applications
Steel
Stainless Steel
Cast Iron
Non-Ferrous
Hardened Steel
Heat Resistant Super Alloy
Steel
Stainless Steel
Cast Iron
Non-Ferrous
Hardened Steel
Heat Resistant Super Alloy
PDF generation may take time depending on details of the product.
| Thread Size - Metric | M10 |
| Thread Type | M |
| Pitch | 1.5 |
| Thread Limit | h6 |
| Chamfer Type | Plug (4.5P) |
| Major Diameter - Metric | 10 |
| Thread Length - Metric (Lc) | 22.2 |
| Tap Drill Size Min - Metric | 8.376 |
| Tap Drill Size Max - Metric | 8.676 |
| Neck Length - Metric (L1) | 35 |
| Overall Length - Metric (L) | 74.6 |
| Shank Diameter - Metric (d) | 9.6774 |
| Square Length - Metric (Ik) | 11.1125 |
| Square Width - Metric (k) | 7.2644 |
| STI Thread | No |
| Substrate | HSS-CO |
| Surface Treatment | TiN |
| Coolant Thru | No |
| Number of Flutes | 3 |
| Cutting Direction | RH |
| Helix Angle - Degree | 0 |
| Interrupted Thread | No |
| View Catalog Page | Here |
| Notes | List 11115 metric taps are manufactured to H-limits rather than D-limits. |
