Cobalt-HSS Drills for Drilling in a Variety of Materials
Steel
Stainless Steel
Cast Iron
Non-Ferrous
Hardened Steel
Steel
Stainless Steel
Cast Iron
Non-Ferrous
Hardened Steel
PDF generation may take time depending on details of the product.
| Diameter - Metric (D) | 3.988 |
| Diameter - Wire Gage (D) | 22 |
| Diameter - Inch (D) | 0.157 |
| Flute Length - Metric (FL) | 26 |
| Overall Length - Metric (L) | 63 |
| Shank Diameter - Inch (d) | 0.1875 |
| Cutting Diameter Tolerance - Inch | +0 / -0.0007 |
| Cutting Diameter Tolerance - Metric | +0 / -0.018 |
| Cutting Diameter Tolerance Specification | h8 |
| Substrate | HSS-CO |
| Surface Treatment | TiN |
| Length of Cut - Specification | JOBBER |
| Drilling L/D Ratio (xD) | 5 |
| Helix Angle - Degree | 25 |
| Point Angle - Degree (α) | 130 |
| Point Thinning | X Thinning |
| Helix Direction | RH |
| Cutting Direction | RH |
| Coolant Thru | No |
| Number of Flutes | 2 |
| View Catalog Page | Here |
| View Speed and Feed Page | Here |
| DXF Drawing | Download |
| STP Drawing | Download |
